HP 764438-001 256GB Multi Level Cell SATA 6Gb/s M.2 2280 Solid State Drive

HP 764438-001 on Discount Price

https://firebasestorage.googleapis.com/v0/b/feisty-etching-333216.appspot.com/o/764438-001.jpg?alt=media&token=9c675b6f-ecf8-497a-b601-82422d40c15c

<p><strong>&nbsp;</strong></p>
<table class="data table additional-attributes" style="height: 489px; width: 91.7319%;">
<tbody>
<tr data-attr="ds_capacity">
<th class="col label" style="width: 41.0297%; text-align: justify;" scope="row">Capacity</th>
<td class="col data" style="width: 58.9275%;" data-th="Capacity">256 GB</td>
</tr>
<tr data-attr="ds_cache_buffer">
<th class="col label" style="width: 41.0297%; text-align: justify;" scope="row">Cache Buffer</th>
<td class="col data" style="width: 58.9275%;" data-th="Cache Buffer">Intelligent SLC Caching Technology</td>
</tr>
<tr data-attr="ds_flash_type">
<th class="col label" style="width: 41.0297%; text-align: justify;" scope="row">Flash Type</th>
<td class="col data" style="width: 58.9275%;" data-th="Flash Type">MLC NAND Flash <a href="https://www.switchtechsupply.com/memory" target="_blank" rel="noopener">Memory </a>(Multi-Level Cell)</td>
</tr>
<tr data-attr="ds_interface_connector">
<th class="col label" style="width: 41.0297%; text-align: justify;" scope="row">Interface Connector</th>
<td class="col data" style="width: 58.9275%;" data-th="Interface Connector">M.2 NGFF (B and M Key)</td>
</tr>
<tr data-attr="ds_interface_speed">
<th class="col label" style="width: 41.0297%; text-align: justify;" scope="row">Interface Speed</th>
<td class="col data" style="width: 58.9275%;" data-th="Interface Speed">SATA III 6Gb/sec</td>
</tr>
<tr data-attr="ds_encryption">
<th class="col label" style="width: 41.0297%; text-align: justify;" scope="row">Encryption</th>
<td class="col data" style="width: 58.9275%;" data-th="Encryption">No</td>
</tr>
<tr data-attr="ds_max_sequential_read">
<th class="col label" style="width: 41.0297%; text-align: justify;" scope="row">Max Sequential Read</th>
<td class="col data" style="width: 58.9275%;" data-th="Max Sequential Read">Up to 450MB/sec (Crystal Disk Mark)</td>
</tr>
<tr data-attr="ds_max_sequential_write">
<th class="col label" style="width: 41.0297%; text-align: justify;" scope="row">Max Sequential Write</th>
<td class="col data" style="width: 58.9275%;" data-th="Max Sequential Write">Up to 300MB/sec (Crystal Disk Mark)</td>
</tr>
<tr data-attr="ds_life_expectancy">
<th class="col label" style="width: 41.0297%; text-align: justify;" scope="row">Life Expectancy</th>
<td class="col data" style="width: 58.9275%;" data-th="Life Expectancy">1 Million Hours (MTBF Mean Time Between Failures)</td>
</tr>
<tr data-attr="ds_shock_resistance">
<th class="col label" style="width: 41.0297%; text-align: justify;" scope="row">Shock Resistance</th>
<td class="col data" style="width: 58.9275%;" data-th="Shock Resistance">1,500G, duration: 0.5ms, 3 axis</td>
</tr>
<tr data-attr="ds_form_factor">
<th class="col label" style="width: 41.0297%; text-align: justify;" scope="row">Form Factor</th>
<td class="col data" style="width: 58.9275%;" data-th="Form Factor">M.2 (2280)</td>
</tr>
<tr data-attr="ds_dimensions">
<th class="col label" style="width: 41.0297%; text-align: justify;" scope="row">Dimensions</th>
<td class="col data" style="width: 58.9275%;" data-th="Dimensions">(L x W x H) 80.15mm x 22.15mm x 2.38mm</td>
</tr>
<tr data-attr="ds_notes">
<th class="col label" style="width: 41.0297%; text-align: justify;" scope="row">Notes</th>
<td class="col data" style="width: 58.9275%;" data-th="Notes">Raw Drive (No Bracket, Connector or Screws)</td>
</tr>
<tr data-attr="ds_name">
<th class="col label" style="width: 41.0297%; text-align: justify;" scope="row">Name</th>
<td class="col data" style="width: 58.9275%;" data-th="Name">Lite-On L8T-256L9G-HP</td>
</tr>
<tr data-attr="ds_OEM_rohs_compliant">
<th class="col label" style="width: 41.0297%; text-align: justify;" scope="row">RoHS Compliant</th>
<td class="col data" style="width: 58.9275%;" data-th="RoHS Compliant">Yes</td>
</tr>
</tbody>
</table>

Storage Devices

764438-001

HP 764438-001 256GB Multi Level Cell SATA 6Gb/s M.2 2280 Solid State Drive

Quantity:

ASK 764438-001 Price

SHOP WITH CONFIDENCE

764438-001 Datasheet

Quick links

Newsletter

Capacity	256 GB
Cache Buffer	Intelligent SLC Caching Technology
Flash Type	MLC NAND Flash Memory (Multi-Level Cell)
Interface Connector	M.2 NGFF (B and M Key)
Interface Speed	SATA III 6Gb/sec
Encryption	No
Max Sequential Read	Up to 450MB/sec (Crystal Disk Mark)
Max Sequential Write	Up to 300MB/sec (Crystal Disk Mark)
Life Expectancy	1 Million Hours (MTBF Mean Time Between Failures)
Shock Resistance	1,500G, duration: 0.5ms, 3 axis
Form Factor	M.2 (2280)
Dimensions	(L x W x H) 80.15mm x 22.15mm x 2.38mm
Notes	Raw Drive (No Bracket, Connector or Screws)
Name	Lite-On L8T-256L9G-HP
RoHS Compliant	Yes
